Synology DS220+ Data Recovery: Retrieving Critical Finance Data After Power Interruption and Recycle Bin Restore Failure
Synology DS220+ Data Recovery: Retrieving Critical Finance Data After Power Interruption and Recycle Bin Restore Failure
Client Scenario
The client is using a Synology DS220+ 2-bay NAS, with 2 x WD Red drives to store company financial data. There was a power interruption occurr. After the NAS rebooted, some folders were missing. Initially, they had access to the NAS normally for one day before noticing the folders were gone. Then they attempted to restore the missing folders from the Recycle Bin. But the restored files are not usable.
System Overview
- Platform: Synology DS220+
- RAID Configuration: RAID 1 (2 × SATA HDDs-WD30EFRX-68EUZN0)
- Storage Type: 2 bays NAS
Assessment Result
Both drives passed inspection as healthy, ruling out hardware failure. The loss was causes by file system errors. The NAS powering off during a power interruption can leave file system and metadata inconsistent, causing folders to disappear from the path while the data blocks may still exist on disk. BUT, when restoring files from the recycle bin, it wrote the data with the same name to the volume, which will causes overwrite.
Technical Emergency Warning Box
If you found your data is gone, stop writing to the volume immediately. Every file created, restored, or modified after the loss may overwrite the missing data. Restoring from the recycle bin, re-copying files, running “repair” tools, or simply keeping the NAS in daily use can permanently overwrite recoverable data.
The Recovery Methodology
- Read-Only Imaging
Each drive was imaged sector by sector using write-blocked hardware so the original drives were never modified during recovery. - Deep Logical Scan
A deep logical scan was run across the volume to locate orphaned directory records, residual metadata, and file signatures. - Overwrite Assessment
Recovered files were evaluated with the post-incident activity. The recovery team prioritizes the mentioned finances and verifies the file's contents. - Verification
Recovered content had been validated, and we arranged a data checking session for the client for cross verification.
Recovery Outcome
A minority of the data was overwritten, but the majority of the critical financial data was recovered successfully. Their finance team accepted all recovered data and manually reworked the overwritten data, saving them hours to weeks of rework from scratch.
Conclusion
Missing folders after a power event are usually recoverable, but only if the data blocks remain intact. When folders disappear from a NAS, power down the unit and stop all read/write activity. Do not attempt restore from the recycle bin, repair utilities, or copy new data to the volume, especially those with the same name.
If you are facing this situation, try to recover data to an external drive to prevent it from being overwritten. Reach out to us only if the recovered data is invalid or corrupted. Click here to contact us if you need further advice.
